Apple iPhone 16 Plus: CSS viewport of 430 × 932 px, resolution and responsive test

Apple · iOS 26.0 · Smartphone · 2024

Released in 2024, Apple iPhone 16 Plus features a CSS viewport of 430 x 932 pixels. Here are all its display characteristics and how to check the responsive rendering of your site on this model.

Test your site on Apple iPhone 16 Plus directly in your browser, without buying the device.

  • Apple iPhone 16 Plus available in the device list
  • Real viewport, User-Agent, and touch events
  • Also works on localhost and in pre-production
  • Exportable screenshots and videos
Install the extension

4.9/5 based on 5,100 reviews · 1,000,000 users · free

Why test your site on Apple iPhone 16 Plus?

Notch and safe areas

On Apple iPhone 16 Plus, the notch and gesture bar reserve part of the screen. Without the env(safe-area-inset-*) variables, your fixed headers and bottom-stuck buttons go under these areas and become unusable.

Large mobile screen

With 430 pixels wide, Apple iPhone 16 Plus already shifts some layouts to their tablet breakpoint. A test prevents overly stretched columns and unreadable text areas.

3x density

Each CSS pixel of Apple iPhone 16 Plus is rendered by 3 physical pixels. Any image, icon, or font provided in simple resolution appears immediately blurry.

CSS viewport resolution of Apple iPhone 16 Plus

This resolution is what your stylesheet actually manipulates. It determines the applied breakpoint, the number of displayed columns, and the size of your images.

  • 430 pixels in width
  • 932 pixels in height

The height remains indicative: Safari, Chrome, and other mobile browsers reduce the visible area with their address bar, which folds on scroll.

Be cautious when analyzing your statistics: some tools only report the manufacturer resolution, never the CSS viewport presented here.

Pixel density of Apple iPhone 16 Plus

3

The device pixel ratio of Apple iPhone 16 Plus is 3.

Each CSS pixel is thus rendered by 3 physical pixels, making any image provided in simple resolution immediately visible.

Manufacturer resolution of Apple iPhone 16 Plus

This is the number of physical pixels on the screen, as announced by the manufacturer. Useful for preparing your image exports, useless for your media queries.

  • 1290 pixels in width
  • 2796 pixels in height
  • 19.5:9 Screen ratio

460 pixels per inch (ppi) · 6.7 inches diagonal, or 17 cm

User-Agent of Apple iPhone 16 Plus

This string is what the browser of Apple iPhone 16 Plus sends. It is useful for your automated tests, reading your server logs, and server-side detection.

User-Agent

User-Agent string used by Apple iPhone 16 Plus, useful for your automated tests and logs.

Mozilla/5.0 (iPhone; CPU iPhone OS 26_0 like Mac OS X) AppleWebKit/605.1.15 (KHTML, like Gecko) Version/26.0 Mobile/15E148 Safari/604.1

Notch and safe areas of Apple iPhone 16 Plus

On Apple iPhone 16 Plus, part of the screen is reserved for the notch and gesture bar. Without precaution, a fixed header goes under the notch, and a bottom-stuck button becomes impossible to touch.

Two conditions to remedy this: declare viewport-fit=cover in the meta viewport tag, then use the env(safe-area-inset-*) variables in your padding.

Safe areas

Protects your fixed elements from the notch and gesture bar of Apple iPhone 16 Plus.

.header {
  padding-top: env(safe-area-inset-top);
}

.bottom-bar {
  padding-bottom: env(safe-area-inset-bottom);
}

Media queries and code snippets for Apple iPhone 16 Plus

These snippets are generated from the exact characteristics of Apple iPhone 16 Plus. Copy them directly into your stylesheet or configuration.

CSS media query

Targets screens whose width matches that of Apple iPhone 16 Plus and models of the same format.

@media only screen and (min-width: 430px) and (max-width: 931px) {
  /* Apple iPhone 16 Plus */
}

Density media query

Serves high-resolution images to screens of at least 3x.

@media only screen and (-webkit-min-device-pixel-ratio: 3),
       only screen and (min-resolution: 288dpi) {
  /* High-density images and icons */
}

Tailwind configuration

Adds a named breakpoint at the exact width of Apple iPhone 16 Plus.

// tailwind.config.js
module.exports = {
  theme: {
    screens: {
      'apple-iphone-16-plus-2024': '430px'
    }
  }
}

JavaScript detection

Detects format and density client-side.

const isDeviceWidth = window.matchMedia('(min-width: 430px)').matches;
const isHighDensity = window.devicePixelRatio >= 3;

Meta viewport tag

Essential for Apple iPhone 16 Plus to use its CSS viewport and not a simulated width of 980 pixels.

<meta name="viewport" content="width=device-width, initial-scale=1, viewport-fit=cover">

Free Apple iPhone 16 Plus simulator

Mobile FIRST includes Apple iPhone 16 Plus: your page displays in a viewport of 430 x 932 pixels, with the model's User-Agent, touch events, and scrolling behavior of a real mobile.

This is where the difference with Chrome DevTools' responsive mode is seen: DevTools resizes a window, the extension replicates the device's browser and allows exporting shareable screenshots and videos.

  1. 01 Install the extension Add Mobile FIRST to Chrome, Firefox, or Edge. Installation is free and requires no account.
  2. 02 Open the page to test Go to the URL to check, including a local address like localhost:3000.
  3. 03 Choose Apple iPhone 16 Plus Select Apple iPhone 16 Plus from the list of devices. The viewport switches to 430 x 932 pixels, and the mobile User-Agent is applied.
  4. 04 Check rendering Scroll, change orientation, test your forms, then capture an image or video to share.

Models sharing the format of Apple iPhone 16 Plus

These 2 devices share exactly the viewport of 430 x 932 pixels and the 3x density of Apple iPhone 16 Plus. Their CSS rendering is therefore exactly the same: what you validate on one is valid on all others.

Comparison with similar models

The neighboring formats of Apple iPhone 16 Plus are the ones to test right after, as they reveal poorly placed breakpoints.

Comparison of resolutions of Apple iPhone 16 Plus and nearby models
Model CSS Viewport Pixel density Manufacturer resolution
Apple iPhone 16 Plus 430 x 932 3x 1290 x 2796
Samsung Galaxy A17 412 x 892 2.625x 1082 x 2342
Google Pixel 8 412 x 915 2.625x 1080 x 2400
Google Pixel 10 412 x 924 2.625x 1082 x 2426
Apple iPhone 15 Plus 430 x 932 3x 1290 x 2796
Apple iPhone 15 PRO MAX 430 x 932 3x 1290 x 2796
Apple iPhone 16 PRO MAX 440 x 956 3x 1320 x 2868

Frequently asked questions about Apple iPhone 16 Plus

What is the CSS viewport resolution of Apple iPhone 16 Plus?

The CSS viewport of Apple iPhone 16 Plus measures 430 pixels wide and 932 pixels high. This is the width to use for defining your media queries, not the manufacturer's resolution.

What is the pixel density of Apple iPhone 16 Plus?

The device pixel ratio of Apple iPhone 16 Plus is 3. Each CSS pixel is thus displayed by 3 physical pixels, requiring you to provide your images in 3x to keep them sharp.

What is the screen resolution of Apple iPhone 16 Plus?

The panel of Apple iPhone 16 Plus displays 1290 x 2796 physical pixels. This is the value reported by most analytics tools, while your CSS works on a viewport of 430 x 932 pixels.

What is the User-Agent of Apple iPhone 16 Plus?

The User-Agent of Apple iPhone 16 Plus is: Mozilla/5.0 (iPhone; CPU iPhone OS 26_0 like Mac OS X) AppleWebKit/605.1.15 (KHTML, like Gecko) Version/26.0 Mobile/15E148 Safari/604.1

Which devices have the same viewport as Apple iPhone 16 Plus?

2 other models share exactly the viewport of 430 x 932 pixels and the 3x density of Apple iPhone 16 Plus: Apple iPhone 15 Plus, Apple iPhone 15 PRO MAX. A rendering validated on one is valid on all others.

How to test my site on Apple iPhone 16 Plus without the device?

Install the Mobile FIRST extension on Chrome, Firefox, or Edge, then select Apple iPhone 16 Plus. Your page displays in a viewport of 430 x 932 pixels with the corresponding mobile User-Agent, in two clicks and for free.

What is the difference with Chrome DevTools' responsive mode?

DevTools resizes the window and applies partial emulation. Mobile FIRST additionally applies the User-Agent of Apple iPhone 16 Plus, touch events, scroll behavior, and the actual appearance of the device, and allows capturing directly usable images and videos.

Can I test a localhost address on Apple iPhone 16 Plus?

Yes. The extension works on any URL open in your browser, including localhost:3000, 127.0.0.1, or a password-protected pre-production environment.

Do you need to buy a Apple iPhone 16 Plus to test your site?

No. The simulation covers the vast majority of development needs at no cost. A final test on a real device is still recommended before critical production deployment, but it's no longer necessary for each iteration.

Which media query to use to target Apple iPhone 16 Plus?

A media query on the exact width targets Apple iPhone 16 Plus: @media only screen and (min-width: 430px). Combine it with the pixel density to precisely target this model and those sharing its format.
